The throttle body is a component of the intake control system in fuel injected engines so as to control the amount of air flow to the engine. This particular mechanism functions by applying pressure upon the driver accelerator pedal input. Normally, the throttle body is placed between the air filter box and the intake manifold. It is often attached to or positioned close to the mass airflow sensor. The biggest component in the throttle body is a butterfly valve called the throttle plate. The throttle plate's main task is in order to control air flow.
On numerous kinds of vehicles, the accelerator pedal motion is communicated via the throttle cable. This activates the throttle linkages that in turn move the throttle plate. In vehicles consisting of electronic throttle control, also known as "drive-by-wire" an electric motor controls the throttle linkages. The accelerator pedal connects to a sensor and not to the throttle body. This sensor sends the pedal position to the ECU or likewise known as Engine Control Unit. The ECU is responsible for determining the throttle opening based on accelerator pedal position along with inputs from different engine sensors. The throttle body has a throttle position sensor. The throttle cable is attached to the black portion on the left hand side which is curved in design. The copper coil located near this is what returns the throttle body to its idle position after the pedal is released.
The throttle plate turns within the throttle body each and every time the operator applies pressure on the accelerator pedal. This opens the throttle passage and permits much more air to be able to flow into the intake manifold. Normally, an airflow sensor measures this adjustment and communicates with the ECU. In response, the Engine Control Unit then increases the amount of fluid being sent to the fuel injectors in order to produce the desired air-fuel ratio. Generally a throttle position sensor or TPS is attached to the shaft of the throttle plate so as to provide the ECU with information on whether the throttle is in the wide-open throttle or otherwise called "WOT" position, the idle position or somewhere in between these two extremes.
Some throttle bodies can have adjustments and valves to be able to control the least amount of airflow throughout the idle period. Even in units that are not "drive-by-wire" there will normally be a small electric motor driven valve, the Idle Air Control Valve or likewise called IACV which the ECU uses to be able to regulate the amount of air that can bypass the main throttle opening.
It is common that a lot of vehicles have a single throttle body, even though, more than one can be utilized and connected together by linkages in order to improve throttle response. High performance automobiles like for instance the BMW M1, together with high performance motorcycles such as the Suzuki Hayabusa have a separate throttle body for each and every cylinder. These models are called ITBs or otherwise known as "individual throttle bodies."
The throttle body and the carburator in a non-injected engine are quite similar. The carburator combines the functionality of both the throttle body and the fuel injectors together. They could modulate the amount of air flow and mix the air and fuel together. Vehicles that have throttle body injection, which is called CFI by Ford and TBI by GM, put the fuel injectors inside the throttle body. This allows an older engine the opportunity to be converted from carburetor to fuel injection without considerably altering the design of the engine.
The IC engine cushion unit lift trucks designed by Yale are manufactured and designed to satisfy the demands of particular applications and industries. The GM in-line 2.4L and 4.3L engines, together with the Mazda 2.0L and 2.2L in-line 4 cylinder engines are very strong, efficient and durable engines. Their design has been specially made and proven for utmost reliability and performance.
Due to their innovative construction and design, Yale's Hi-Vis masts offer unsurpassed visibility and excellent construction. Every part has been engineered for low-maintenance, extended life and excellent performance. These models are really well designed to be a leader in the business.
Outriggers and Frame
The outrigger and frame of the lift truck should be able to handle harsh environments in order to efficiently and safely handle the daily stresses it is likely to encounter. The frames made by Yale provide maximum protection to all of the components of the lift truck. Furthermore, they support the equipment and give it a long life and optimal strength.
In order to make certain that their machines satisfy the requirements and expectations of their customers, Yale frames have been subject to extensive laboratory, computer and application testing. For extra capacity and support, outriggers are directly welded to the frame. These major components must be able to effectively deal with the stresses of the most throughput reach truck condition.
